型號規格（model） |
進料口尺寸(mm) |
最.大給料粒度(mm) |
排料口調整范圍(mm) |
處理能力(t/h) |
電機功率(kw) |
|
PE-250×400 |
250×400 |
210 |
20-60 |
4.5-20 |
15 |
|
PE-400x600 |
400x600 |
340 |
40-100 |
15-53 |
30 |
|
PE-500x750 |
500x750 |
425 |
50-100 |
38-90 |
55 |
|
PE-600x900 |
600x900 |
500 |
65-180 |
45-128 |
55-75 |
|
PE-750x1060 |
750x1060 |
630 |
80-180 |
108-225 |
90-110 |
|
PE-800x1060 |
800x1060 |
650 |
100-200 |
128-215 |
90-110 |
|
PE-870x1060 |
870x1060 |
750 |
170-270 |
218-353 |
90-110 |
|
PE-900x1060 |
900x1060 |
780 |
200-290 |
255-375 |
90-110 |
|
PE-900x1200 |
900x1200 |
780 |
95-255 |
220-450 |
110-132 |
|
PE-1000x1200 |
1000x1200 |
850 |
195-280 |
315-500 |
110-132 |
|
PE-1200x1500 |
1200x1500 |
1020 |
150-300 |
400-800 |
160 |
|
PE-1500x1800 |
1500x1800 |
1200 |
220-350 |
500-1000 |
180 |
|
PEX-150x750 |
150x750 |
120 |
18-48 |
8-25 |
15 |
|
PEX-250x750 |
250x750 |
210 |
25-60 |
13-35 |
22 |
|
PEX-250x1000 |
250x1000 |
210 |
25-60 |
16-52 |
30-37 |
|
PEX-250x1200 |
250x1200 |
210 |
25-60 |
20-61 |
37 |
|
PEX-300x1300 |
300x1300 |
250 |
20-90 |
16-105 |
55 |
|
PEX-500x1500 |
500x1500 |
350 |
30-110 |
30-110 |
90 |
